Brushless electric motor for model aircraft: 1800g glider, 1700g trainer, 1300g acro, 1050g 3D, KV8500 RPM/V, input voltage 3-4S Lixx. Shaft of 5,0 mm. Alternative designation based on stator size: 2814-850.
Power supply for LiXX 3 - 4 cells
RPM/V [ot./min/V] 850
Maximum power (180 s) [W] 650
Internal resistance [mOhm] 43
Open circuit current (při 10 V) [A] 1.2
Max. peak current (180 s) [A] 45
Diameter [mm] 35.2
Length [mm] 34
Celková length [mm] 54.5
Shaft diameter [mm] 5
Weight [g] 108
Number of poles 14
Time [°] 20 - 25
ESC [A] 45 - 60
Glider weight (up to) [g] 1800
Weight of the trainer (up to) [g] 1700
Weight of the acrobat (up to) [g] 1300
3D weight (to) [g] 1050
