Brushless electric motor for model aircraft: glider 2400g, trainer 2300g, acro 2000g, 3D 1500g, KV950 RPM/V, input voltage 3-4S Lixx. Shaft of 5.0 mm. Alternative designation based on stator size: 2820-950.
Power supply for LiXX 3 - 4 cells
RPM/V [ot./min/V] 950
Maximum power (180 s) [W] 900
Internal resistance [mOhm] 28
Open circuit current (při 10 V) [A] 2
Max. peak current (180 s) [A] 65
Diameter [mm] 35.2
Length [mm] 41
Celková length [mm] 63.5
Shaft diameter [mm] 5
Weight [g] 139
Number of poles 14
Time [°] 20 - 25
ESC [A] 70 - 80
Glider weight (up to) [g] 2400
Trainer weight (up to) [g] 2300
Weight of the acrobat (up to) [g] 2000
3D weight (up to) [g] 1500
