With MULTImate or with Sensor Data Manager on PC, activation and settings are possible:
Address Address (line of the transmitter display), under which the rate of climb is displayed
High alarm threshold Upper threshold of the rate of climb, from which the alarm is triggered on the transmitter
Low alarm threshold Lower threshold of the rate of climb, from which the alarm is triggered on the transmitter
Option Additional display of the min., average or max. rates of climb
Option Address Address (line on the transmitter display) under which the optional value is displayed
Integration Integration time - Interval, from which altitude changes are to be integrated
... Same as for the altimeter (without integration time)
Technical data:
Measuring range of the altimeter
-500 ... +2000 m
(from take-off point)
Altimeter resolution 1 m
Vario measuring range +/-50 m/s
Vario resolution 0,1 m/s
Housing dimensions (L x W x H)
31 x 20 x 9 mm
Weight approx. 10 g
