Propulsion Sets - Combo ECO 3520C V2 820kv (210g, 1040W) + 65A Lite Controller - FLASH RC

Propulsion Sets - Combo ECO 3520C V2 820kv (210g, 1040W) + 65A Lite Controller - FLASH RC

ECO 3520C V2 820kv Combo (210g, 1040W) + 65A Lite Controller

Out-of-Stock

€70.83

Tax included

This engine+controller combo is suitable for aerobatic aircraft up to 2.4Kg and 3D models up to 1.6Kg. Delivered with a faixation cross and propeller holder (rotor side).

Technical data of the motor

KV: 820RPM/V
Weight: 210g
Diameter: 42mm
Length: 49mm
Shaft diameter: 5.0mm
No load current (Io) @10V: 1.50A
Internal resistance (Ri): 42mOhm
Peak power consumption [15s]: 65A
Peak power [15s]: 1040W
Recommended propeller: 5S LiPo, 15x8 / 6S LiPo, 15x6

Technical data of the controller

Dimensions: 75x 30x 14mm
Weight: 63g
Supply voltage: NiXX 6-18, 7.2-21.6V, LiPo 2-6, 7.4-22.2V
Internal resistance (Ri)(Ohm): 0.0022
Max. current & Max. power 65A, 1260W
Max. peak current & max. peak power: 80A, 1632W
BEC: 5.5V/3A
Programmable: with the motor handle or with the ProgCARD V2
Input cables: 150mm, 12AWG, DC3 male plug
Output cables: 90mm, 14AWG, 3 DB4 plugs
Receiver wire: 300MM JR

Motor power in Watts: 1040
Revs/ minute Kv: 820

Reference 016-TC.5A.40E

EAN13 6941047191105

MPN 6941047191105

No reviews

Comments (0)

No customer reviews for the moment.
