Savox SH-0256 micro digital servo (16g, 4.6kg.cm, 0.16s/60°)

Out-of-Stock
€16.58
Tax included
The aluminum housing is waterproof, allowing it to be used in wet or dusty conditions. This servo is suitable for use on 450 helicopters and parkflyer aircraft.


custom html
you can configure this block in iqithtmlbanners module. It is hooked in displayRightColumnProduct hook.

To disable entire area go to iqitthemeeditor module > Content/Pages > Product page and set hidden for Right sidebar option


Technical specifications

  • Dimensions (mm): 22.8X12.0X29.4
  • Weight (g): 15.8
  • Speed: 0.21 sec/60° (4.8V), 0.16 sec/60° (6.0V)
  • Torque : 3.9 Kg.cm (4.8V), 4.6Kg.cm (6.0V)
  • Frequency : 333 Hz
  • Pulse length : 1500 µs
  • DC motor
  • Metal & nylon gears
  • 1x bearing
  • Aluminium housing
  • Output gear : 21 teeth

Thickness in mm (Servos)
12
Torque in kg.cm (servos)
4.6
Speed sec / 60° (servos)
0.16
Pinions (servos)
Plastic
Bearing (servos)
yes
Technology (sevos)
Digital
HV (servos)
no
Weight in g (servos)
16
191-SH-0256
4710006990217
4710006990217
