In addition, the motor cut-off is automatically determined according to the flight mode set on the controller depending on the voltage at start-up, thus avoiding overcharging of the battery.
For motors: Brushless
Number of cells/Battery type: 2-4 LiPo 6-12 Nixx
Continuous current rating: 60A
Maximum power: 1000W
BEC circuit type: Switching 5V/2.5A continuous
OPTO: NO
Weight: 45.2g
Dimensions: 78.0x35.0x10.6mm
Application: brushless motors up to 60A
Light, compact and particularly thin, these controllers will work wonders in thin fuselages of gliders for example.
This controller has a safety device of throttle at the powering on, thus not allowing the use of device such as the "ALTIMETERS RECORDERS" for the category F5J for example.
