Replaces the HPS-A701 servo, with the same features but using a new-generation microprocessor.
Replaces the HPS-A701 servo. Same features but uses a new-generation microprocessor.
Low-profile servo for RC aircraft. New HPS brushless motor technology specially designed for higher performance and better cooling.
Technical specifications:
- For large-scale aircraft. - Programmable/high-performance brushless servo.
- New brushless motor.
- Specially developed for the F3A.
- Programmable and compatible with S.Bus and S.Bus2 systems.
- Can be connected to a PC using the CIU-2/-3 USB adapter sold separately.
- Metal output gear. Metal output gear.
- Top/middle/bottom: plastic housing
Speed:
0.07 s/60° at 6.6 V
0.06 s/60° at 7.4 V
Torque:
14.5 kgf/cm at 6.6 V
16.0 kgf/cm at 7.4 V
Dimensions:
40.5 mm x 21 mm x 26.9 mm
Weight:48g
Nominal voltage: DC 6.0V-7.4V
Operating voltage: DC 4.8-8.4V
DO NOT USE DRY BATTERIES OR BECKS
