NEW: In conjunction with the FUTABA SBS-01ML S.BUS sensor adapter (coming soon), the transmitter supports the MAVLink protocol. MAVLink or Micro Air Vehicle Link is a protocol for communicating with small unmanned vehicles. It's a simple messaging protocol for communicating with drones (and between drones' onboard components). MAVLink follows a modern hybrid publish-subscribe and point-to-point design model: data streams are sent/published as topics, while configuration sub-protocols such as the mission log or parameter log are point-to-point with retransmission.
Technical specifications:
* 16 proportional channels, + 2 inters.
* FASSTest, S-FHSS and T-FHSS compatible.
* Software upgradeable.
* 4.3" color touchscreen
* 30 model memories
* 15-character user and model name.
* Sub Trim
* Reverse Servos
* Trim : réglage taux mode....
* Servo speed
* DR/AFR
* AFR curve (3)
* AFR curve (17 points)
* Logic inter
* Flight conditions (8)
* 10 free mixes * SBUS servo tuning program
* SD card slot
* Earphone socket (voice messages)
* Stopwatches
* Inters, knobs, levers, trims (assignable)
* Buzzer and vibration alarm
* Schooling socket
* Multi language
AIRCRAFT PROGRAMS
HELICOPTERS PROGRAMS
PLANES PROGRAMS
MULTICOPTER PROGRAMS
TELEMETRY FUNCTIONS
All functions, mixes and possibilities are not listed above, otherwise at least 3 pages of presentation would be needed!
Kit contents:
- Transmitter in mode 2
- Receiver R7208SB
- Transmitter battery Li-Po 7.4V2100 mAh
- USB charging cable
- 1 switch cable
- 1 quick user's guide
NOT INCLUDED:
- Power supply to charge the battery (see option reference 01000308) However, you can use any commercially available USB power supply (5V-2A)
Compatible receivers:
In FASSTest 18CH:
R7003SB
R7006SB
R7008SB
R7014SB
In FASSTest 12CH:
R7003SB
R7006SB
R7008SB
R7014SB
R7018SB
In T-FHSS Air:
R3001SB
R3006SB
R3008SB
R3106GF
In S-FHSS:
R203GF
R204GF-E
R2001SB
R2006GS
R2008SB
R2104GF
R2106GF
