Some details:
- High S-BEC (except OPTO HV)
- Additional connection cable to the receiver to minimize contact resistance and increase safety
- Easy programming with the optional ROXXY PROcontrol Programmer 02110
- Compatible with outrunner and inrunner motors running at high speed
- Soft start and linear throttle curve
- Motor Timing (advance) function for automatic timing
- Two different Governor modes can be selected in combination with a helicopter
- Equipped with high-efficiency MOSFET transistors, the drive is compact and lightweight, and its very low internal resistance allows for extremely high loads
- Generously dimensioned aluminum housing ensures good heat dissipation
- The high voltage types (HV OPTO) are equipped with an anti-arcing system.
On other drive types, we recommend using a connector with anti-arcing system.
Technical data:
- Dimensions: 33 mm x 16 mm x 78 mm
- Weight: 0.093 kg
- Continuous current: 65 A
- Number of cells: 2-6 LiPo, 5-18 NiMH
- BEC-Strom: 8 A
- Receiver Power supply: Yes
- Telemetry: No
- Brake type setting : off, soft, medium, hard
- Battery type selection : NiCd / NiMH, LiPo, LiFe
- Undervoltage threshold:
- Li-xx: low (2.8 V per cell), medium (3.0 V per cell), high (3.2 V per cell), undervoltage cut-off disabled
- Ni-xx: low (50% of initial voltage), medium (60% of initial voltage), high (65% of initial voltage) - Timing:
- Auto: the drive calculates the optimal timing automatically
- 2°: for most internal rotor motors
- 8°: for most internal rotor motors
- 15°: for multipole motors (6 or more poles)
- 22°: for multipole motors (6 or more poles)
- 30°: for multipole motors - S-BEC voltage selection (except OPTO HV)
- Level 1: 5.0 V
- Level 2: 6.0 V
- Level 3: 7.4 V
- Level 4: 8.4 V - Activation of the speed control (helicopter): RPM off, Soft Start (& 2 Governor modes)
- Reversal of rotation direction
- Motor start selection on 9 levels
- Engine cut-off:
- Reduce power, reduce engine speed.
- Engine cut off.
Contents of the box:
(1) Roxxy PROcontrol
(1) Operating instructions
