Magnetic switch - SKY RC
Magnetic switch - SKY RC
Magnetic switch - SKY RC
Magnetic switch - SKY RC

Magnetic switch - SKY RC

€14.16
Tax included

custom html
you can configure this block in iqithtmlbanners module. It is hooked in displayRightColumnProduct hook.

To disable entire area go to iqitthemeeditor module > Content/Pages > Product page and set hidden for Right sidebar option


Effortlessly activate your RC model's receiver with a simple flick of the magnet.


Safely integrated into your installation, it offers transparent control and intuitive operation, eliminating the drawbacks of traditional switches.


A simple flick of the magnet and you're ready to go: power!

How to use:

1 - Activating the switch

  • Place the magnet directly over the sensitive area (1.0 to 1.5 cm above the LED) to turn on the switch.
  • The green LED will light up to indicate that the output device is powered.

2 - Switch off

  • To switch off the switch, pass the magnet over the sensitive area again.
  • The green LED will go out to indicate that the output device is no longer powered.

3 - Status memory in case of power failure

  • If the power is cut, but restored within 10 seconds, the switch returns to its previous state.
  • If the power supply is cut for more than 10 seconds, the ON/OFF status is randomized after the power supply is restored.

Technical specifications
ElementDescription
Supply voltageDC 3-13V
No-load current<5uA (when output is off)
<3.5mA (when output is on)
Max continuous output current 7A
Max. peak output current10A
Magnet operating range 1.0-1.5cm above LED indicator
LED indicatorGreen ON: active
Green OFF: inactive
Power on status<10 seconds: Previous state restored
>10 seconds: Switch enters random state.
Product contents
  • 1 x MPS010 magnetic switch
  • 1 x Activation magnet
  • 1 x Manual
  • 1 x Location sticker
Product features
  • Manufacturer : SkyRC
096-SKY600155-01
