Dualsky XM6352DA-26 V4 F3A motor - (490g, 3000W, 220KV)

Last items in stock

€199.99

Tax included

Dualsky motor specially designed for F3A competition aircraft up to 6.4kg. These motors have a long shaft, high quality magnets and a winding designed for an optimized KV. A motor mount (sold separately) allows the motor to be installed in front of the firewall. Dynamically balanced motor, with curved magnets for better rendering.

Technical data

KV: 220 rpm/V
Stator diameter: 53 mm
Shaft diameter: M8
Weight: 491g (without accessories)
Resistance (Ri): 43mOhm
No-load power consumption (Io) @10V: 0.7A
Number of cells (LiPo): 10
Max. peak current (15s): 75A
Max. peak power (15s): 3100W
Max. weight aircraft type F3A: 6.4kg
Max. glider weight: 12kg
Recommended controller: 100A
Propeller range: 19x12"...21x10"

Engine weight: More than 1000g/1kg
Motor power in Watts: 3000
Revs/ minute Kv: 220
Type of tree: with tray

Reference 016-XM6352DA-26

EAN13 6941047120303

MPN 6941047120303
